Wall box VAS 681 009

Wall box VAS 681 009, for Type 2 connectors, is a modern solution for charging electric vehicles outdoors using alternating current (AC). Not suitable as a mobile charging point. The wall box is supplied pre-configured with a SIM card so that connection to the Elli backend system is guaranteed.
When selecting a location, please consider the possibility of a stable LTE connection. If no LTE is available, additional measures may be necessary (changeover to LAN or external LTE aerial).
These measures must be implemented independently.
We recommend laying a duplex network cable (CAT 7) as well as the power supply cable for each charging station/home charging station.

Billing: This wall box has a kW/h meter, which is not compliant with the Measurement and Verification Acts in all Member States of the EU and therefore does not guarantee billable public charging, such as in Germany and Austria. For these markets, in which MID-approved charging stations are prescribed, we recommend the identical wall box VAS 681 015 with integrated electricity meter.

Market approval: EU27 + Switzerland, UK and Norway

Note: Dealerships and importers should be familiar with country-specific legal and technical requirements for charging stations and infrastructure. Such as:
- Measurement and Verification Acts
- Billing
- Minimum technical requirements for safe and interoperable design and operation of publicly accessible charging points for electric vehicles
- Please take into account the required maintenance in accordance with the manufacturer’s specifications.

Note on the Elli backend: After on-site installation of the charging station, a connection to the Elli backend is established via the built-in SIM card. Commissioning via an app is not necessary.
The charging station can be operated using the RFID cards included in the scope of delivery (and other RFID cards).
To use the ""Elli Charging Site Management"" Elli software (expected to be available from Q4/2020), registration with Elli is required. See the Elli brief guide included in the scope of delivery.

Technical data:
- Charging power: max. 11 kW AC (pre-configured)
- Dimensions: 450x180x126 mm (without wall bracket)
- Weight: 3.5 kg (with wall bracket)
- Charging mode: mode 3 (IEC 61851)
- Number of charging points: 1
- Charging points: Type 2 connector with shutter as per DIN EN 62196-2
- Authentication: RFID charging card
- IP rating: IP55
- Voltage supply, nominal frequency: single phase: 230 V AC, 3-phase: 400 V AC / 3~ / N / PE, 50 Hz

Delivery includes:
- Wall box
- Wall bracket
- Five RFID cards
(charging cable is not included in the items supplied)
- Elli brief guide to connecting the charging station

Recommended accessories
This wall bracket can be mounted flexibly on a suitable wall or on stand VAS 681 009/2 or VAS 681 009/3.
- Stand VAS 681009/2 = 1,208 mm high (without battery window)
- Stand VAS 681009/3 = 1,608 mm high (with battery window)
A concrete pedestal VAS 681009/2-2 is required for stands VAS 681009/2 and VAS681009/3. In addition cable holder VAS 681009/2-1 can be secured on the stands VAS 681009/2 and VAS681009/3.

#--- ASE 681 009 00 000 ---#

Scope of delivery

Technical information

Dimensions of the package (l X w X h)
455 / 340 / 180
